Wireline

✓. MultiFinger Caliper Tool – MFCT - Want to address internal corrosion in casing/tubing effectively? The MFCT comes in various diameters to fit different casing and tubing sizes. As diameter increases, so does the number of fingers for optimal surface coverage. It works with other Well Integrity tools and provides 3D pipe condition images and analysis using specific software.
✓. Magnetic Thickness Tool – MTT - Want to address corrosion damage outside casing/tubing effectively? The Magnetic Thickness Tool (MTT) measures pipe metal thickness variations with twelve sensors mounted on bow springs, allowing it to pass through tubing and log casing up to 9 5/8″. It measures internal diameter accurately and detects external metal loss, addressing corrosion damage outside the casing/tubing.
✓. Cement Bond Logs – RBL - How can our RBT tools assess cement bond quality and hydraulic isolation? The RBT dual spaced 3ft-5ft CBL offers an economical cement job evaluation. Radial Incremental Bond (RIB) tools include CBL-VDL receivers and radial receivers to detect cement channeling. RBT assesses cement bond quality, hydraulic isolation, identifies micro annulus and channeling, and locates the top of cement (TOC).

✓. QUAD NEUTRON™ Thru Pipe Formation Evaluation - Need a tool that logs through casing and drill pipe efficiently? The Quad Neutron is a four-detector tool designed for through-pipe reservoir evaluation. It includes Natural Gamma Ray, CCL, temperature, fluid resistivity, and accelerometer sensors. Ideal for high-risk horizontal wells, it logs through casing and drill pipe, identifying high water saturation, bypassed hydrocarbons, shale formations, and aiding fracture planning.

✓. PLT – Looking for production evaluation and flow profiling with a very compact tool? Field-proven Production Logging Tools (PLT) use multiple sensors to deliver accurate downhole production data, describing fluid behavior in wells. The PLT string operates in real-time or memory mode.
Applications:
– Production evaluation
– Flow profiling
– Water identification
– Leak detection
– Perforation identification
– Reservoir & production evaluation
– Downhole well testing
✓. Noise Temperature Tool – NTL – How can our Noise Tool identify flow changes and obstructions? The Noise Tool detects fluid movement in cased-hole producing wells using microphones. It identifies flow changes caused by varying rates or pressure, detecting channels behind the casing, flow obstructions, and casing leaks. Noise logs are created from stationary samples and can be stacked with gamma ray, CCL, and temperature tools for enhanced analysis.

✓. Select Fire & Pump Down – How can our completions systems optimize your horizontal wells? Kodiak provides customized completions systems and well application systems to meet unique customer needs and well applications. With the increase in horizontal and non-conventional well completions new solutions for customers was obvious.
✓. Plug & Packer Setting Tools – How can our Size 05-10-20 series improve your well operations? The different Tools we provide offers reliable, efficient setting tools at an affordable price. The Size 05-10-20 series improves on a classic design, providing rugged performance. The compact type tools are ideal for pump-down frac jobs, also handles plugs/packers needing longer strokes. All models use gas pressure and hydraulic cushioning for safe, effective setting
✓. Gamma Ray – Perforating (GR) - How does our Scintillation sensor confirm shooting intervals? The Scintillation sensor detects gamma rays from the formation to identify hydrocarbon and water zones, confirming shooting intervals. Kodiak’s Gun Gamma Rays tool allows for simultaneous GR-CCL logging during perforation, saving rig time. It is ideal for situations where a standard CCL log cannot be performed.
✓. Tubing Conveyed Perforating (TCP) Select Fire Options - Want a flexible TCP system for vertical, deviated, or horizontal wells? Tubing Conveyed Perforating (TCP) offers a cost-effective solution for well completions in vertical, deviated, or horizontal wells. TCP systems allow unlimited gun lengths, can be run on coiled or jointed tubing, and enable quicker production start-up. Kodiak provides various TCP systems, customizable to meet specific customer needs.
✓. Perforating Gun Systems - Need precise perforations to maximize well productivity? Maximizing well productivity requires precise perforations. Kodiak’s hollow carrier and capsule perforating guns are optimized for wellbore and reservoir conditions.
Charges:
Super Deep Penetrating (SDP): Unmatched penetration with large holes for improved flow.
Good Hole/Deep Penetration (GH/DP): Balance between hole size and penetration.
Big Hole (BH): Largest hole diameter for enhanced flow, ideal for gravel or frac pack operations.

✓. Thru Tubing Plug (T-TP) – How can our T-TP pass through small restrictions and set up to 8 times its run-in diameter? T-TBP pass thru small diameter restrictions and can set in diameters up to 8 times their run-in diameter. Cement slurry is placed atop the plug to achieve long-term pressure isolation. Over 30.000 WL-run T-TBPs have been successfully run throughout the global oil industry.
T-TBPs can run on WL, Slickline and CT. They provide a platform upon which Super Slurry cement is placed. The cement sets and bonds to casing, therein, providing a long term high ΔP casing plug.
✓. Dump Bailer - Need a technically superior dump bailer for precise operations? Dump bailers for cement, acid, or sand operations come in two types: positive-displacement (PD) and gravity-feed. The PD bailer uses a solenoid-triggered weight to release contents without explosives, making it technically superior. The gravity-feed bailer, the industry standard, uses explosives to break a disk, allowing cement flow.

✓. Free Point Indicator Tool (FPIT) (Product) - Looking for a reliable solution to assess and free stuck assemblies? The FPIT free-point indicator tool identifies the stuck point in drill pipe, collars, tubing, or casing being very effective allowing saving time and costs in this type of operations. It assesses the stuck assembly and, with a Backoff Shot, uses explosive force to free the section.
✓. Chemical Cutter (Product) - Need a precise tool for cutting tubing without explosives? The chemical cutter uses an igniter to initiate a gas generator, increasing pressure to anchor the tool in place. Bromine trifluoride is released through a catalyst, igniting steel wool and raising pressure. Once it exceeds well pressure, the chemical is forced through orifices, cutting the tubing. The tool is then released and retrieved.
✓. Jet Cutters (Product) - Want a clean, effective cut with shaped charge technology? Jet Cutters are explosive shaped charges designed to give a 360˚ cut by the use of a jet that is formed from the shaped charge. These cutters are ranged for coiled tubing up to different sizes in casing.
✓. Radial Cutting and Pyro Torch™ (RCT™) - Fast mobilization response in your operations with safest and efficient pipe cutting or punching devices needed? MCR Oil Tools are the safest and most efficient pipe cutting or punching devices because it uses patented technology to sever tubing, casing, drill pipe, and coiled tubing without explosives.
